True RMS Digital Multimeter with Analog Bar Graph Temp Sensor Test AC/DC Voltage Ammeter Current Ohm multi tester
1.Can measure AC/DC voltage, AC/DC current, resistance, capacitance, frequency, duty cycle, diode, continuity, NCV and
2.Portable Design: It's small and handheld, there is a back bracket for supporting multimeter.
3.Wide range of applications: It's a perfect tool for the laboratory, factory and home.
4.Easy to use & clear to read: With large LCD Backlight display and data hold, convenient to read data in the dark.
5.More advantages: Auto range, true RMS, auto power off, low battery indication and over range indication.
1.This MultiMeter is a handheld digital multimeter, high reliability and portability, a perfect tool for the laboratory, factory
2.It can measure AC/DC voltage, AC/DC current, resistance, capacitance,
frequency, duty cycle, diode, continuity, NCV and temperature.
3.Moreover,more advantages such as backlight, data hold, auto range, true RMS, auto power off, low battery indication and over
Color: Black & Red
Data hold: Yes
Auto range: Yes
True RMS: Yes
Auto power off: Yes
Low voltage indication: Yes
Over range indication: Yes
Diode test: Yes
Continuity test: Yes
NCV test: Yes
DC voltage: 999.9mV/9.999V/99.99V/999.9V±(0.5%+3),9.999mV/99.99mV±(0.5%+3)
AC voltage: 999.9mV/9.999V/99.99V/750V±(1.0%+3),9.999mV/99.99mV±(1.0%+3)
DC current: 999.9mA/9.999A±(1.0%+3),99.99mA/9999μA±(0.8%+3)
AC current: 999.9mA/9.999A±(1.2%+3),99.99mA/9999μA±(1.0%+3)
Frequency:99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/5.000MHz ±(0.1% + 2)
Duty Cycle:1%~99%±( 0.1%+2)
Supply power:6F22 9V battery (not included)
